Cables Belden para Seguridad y Alarma, Aplicaciones Comerciales, Cable Blindado
N E W G E N E R A T I O N ® C A B L E S
Security and Alarm Cable
Commercial Applications
Shielded
Shielded Multi-conductor
CMR/CMG FT4 Rated
Números de Parte:
5600FE, 5520FE, 5500FE, 5521FE, 5501FE, 5502FE, 5503FE, 5504FE, 5506FE, 5508FE, 5400FE, 5401FE, 5402FE, 5403FE, 5405FE, 5407FE, 5320FE, 5300FE, 5301FE, 5302FE, 5303FE, 5304FE, 5305FE, 5306FE, 5307FE, 5200FE, 5201FE, 5201FE, 5202FE, 5100FE, 5101FE, 5000FE.
Catálogo y Hoja Técnica.
http://www.belden.com/products/catalogs/mastercatalog/brilliance/upload/20-8_27.pdf
Video de Cables Belden
Part No. of
No. Cond.
Product Description
Bare copper conductors, PVC insulation, cabled, Shielded Multi-conductor (NEC CMR and CEC CMG
Beldfoil® shield tape (foil side out) with drain wire, 24 AWG
Gray PVC jacket with rip cord. Sequential footage 5600FE 2 7 U-1000 U-305 11.0 5.0 .015 .38 .120 3.05
marking every two feet. 1000 305 10.0 4.5
Color Code: See chart below. 22 AWG
5520FE 2 solid C-500 C-152 6.5 3.0 .015 .38 .125 3.18
Specifications C-1000 C-305 13.0 5.9
U-1000 U-305 14.0 6.4
Conductor Bare Copper 1000 305 14.0 6.4
Insulation PVC
Insulation Thickness .010″ (.254mm)
Shield Beldfoil
Jacket PVC
5500FE 2 7 C-500
U-500
500
U-1000
1000
C-152 5.5 2.5 .015 .38 .130 3.30
U-152 6.5 3.0
152 6.5 3.0
U-305 12.0 5.4
305 12.0 5.4
Approvals 5521FE 3 solid U-1000 U-305 12.0 5.4 .015 .38 .132 3.35
NEC CMR 1000 305 12.0 5.4
CEC CMG FT4
NEC Articles 800
Voltage Rating 300V
Temperature Rating 75°C
5501FE 3 7 C-500
U-500
500
U-1000
1000
C-152 7.0 3.2 .015 .38 .138 3.51
U-152 8.0 3.6
152 7.5 3.4
U-305 15.0 6.8
305 15.0 6.8
Applications
• Security Systems
• Intercom/PA Systems
• Sound/Audio Systems
• Power-Limited Controls
Solid Conductor
5502FE 4 7 C-500
U-500
500
U-1000
1000
5503FE 5 7 1000
5504FE 6 7 C-500
U-500
U-1000
1000
C-152 8.5 3.9 .015 .38 .152 3.86
U-152 9.5 4.3
152 9.5 4.3
U-305 18.0 8.2
305 18.0 8.2
305 22.0 10.0 .015 .38 .165 4.19
C-152 13.5 6.1 .015 .38 .179 4.55
U-152 15.0 6.8
U-305 29.0 13.2
305 29.0 13.2
5506FE 8 7 U-500 U-152 16.5 7.5 .015 .38 .196 4.98
U-1000 U-305 32.0 14.5
Shorting Fold 1000 305 32.0 14.5
5508FE
Stranded Conductor
10 7 U-500 U-152
U-1000 U-305
1000 305
19.5 8.9 .015 .38 .230 5.84
38.0 17.2
44.0 20.0
20 AWG
5400FE 2
Shorting Fold
7 C-500 C-152 8.0
U-500 U-152 9.0
500 152 8.5
U-1000 U-305 17.0
1000 305 17.0
3.6 .015 .38 .145 3.68
4.1
3.9
7.2
7.2
Color Code Chart
Cond. No. Color
1 Black
2 Red
3 White
4 Green
5 Brown
6 Blue
7 Orange
8 Yellow
9 Purple
10 Gray
5401FE 3 7 U-500
500
U-1000
1000
5402FE 4 7 C-500
U-500
500
U-1000
1000
5403FE 5 7 U-1000
1000
5405FE 7 7 U-1000
1000
5407FE 9 7 1000
U-152 11.0 5.0 .015 .38 .153 3.89
152 10.5 4.8
U-305 21.0 9.5
305 21.0 9.5
C-152 12.0 5.4 .015 .38 .168 4.27
U-152 12.5 5.7
152 13.0 5.9
U-305 25.0 11.3
305 26.0 11.8
U-305 30.0 13.6 .015 .38 .184 4.67
305 30.0 13.6
U-305 39.0 17.7 .015 .38 .201 5.11
305 40.0 18.2
305 51.0 23.2 .015 .38 .236 5.99
