HOOK UP & LEAD WIRE, UL AWM Style 3191 600V, 105°C │

UL AWM Style 3191
600V, 105°C
(CSA Type CL1053)
Product Description
This insulation is chlorosulfonated
polyethylene. Hypalon insulation has
excellent heat resistance, color stability
and electrical properties. Hypalon is
recommended for motor leads for Class
130(B) insulation systems. It may be
considered as an alternative to Silicone
rubber to withstand 155°C varnish
baking temperatures, but is not suitable
for operating temperatures above
Class 130(B).
Recommended maximum baking cycles:
24 hours @ 300°F (149°C)

UL AWM Style 3191, 3192, 3193
600V, 105°C
(CSA Type CL1052, 300V)
Product Description
This insulation is chlorosulfonated
polyethylene. Hypalon insulation has
excellent heat resistance, color stability
and electrical properties. Hypalon is
recommended for motor leads for Class
130(B) insulation systems. It may be
considered as an alternative to Silicone
rubber to withstand 155°C varnish
baking temperatures, but is not suitable
for operating temperatures above
Class 130(B).
Recommended maximum baking cycles:
24 hours @ 300°F (149°C)

Numero de Parte Belden: 34418, 34416, 34414, 34412, 34410, 34408, 34406, 34404, 34403, 34402, 34401, 34490, 34400, 34430, 34440
