Overall Foil Braid RS 232 422 PP Insulation

Overall Foil Braid RS 232 422 PP Insulation

Multipair cable Overall Foil Braid RS 232 422 PP Insulation

B9804, B9805, B9806, B9807, B9808, B9809, B9812, B9813, B9819, B9825, B9814

Somos Especialistas en Cables. Distribuimos en toda la Republica Mexicana: Innovative Trade Center, Tel: (664) 621 33 36 / 621 30 09 ventas@innovative.com.mx, soporte@innovative.com.mx, Tijuana, B. C. www.innovative.com.mx

Multipair cable Overall Foil Braid RS 232 422 PP Insulation

BELDEN
ESPECIFICACIONES DE Multipair cable
1. Los conductores: 28 AWG (7×36) de cobre estañado
2. AISLAMIENTO: Polipropileno
3. CHAQUETA: Cromo PVC, consulte la Tabla 3 para el código de color
4. Blindaje: En general Beldfoil (100% de cobertura), pantalla de malla de cobre estañado (cobertura del 90%),
28 AWG hilo trenzado de cobre estañado
5. NORMAS: UL AWM Style 2960, NEC CL2:
6. VALORACIÓN: 30 V (AWM), 150 V (CL2), -20 ° C a 60 ° C, 100 ohmios de impedancia nominal, el 66% de la velocidad de propagación, 15.5 pF / ft. capacidad

Multipair cable Overall Foil Braid RS 232 422 PP Insulation

BELDEN
SPECIFICATIONS Multipair cable
1. CONDUCTORS: 28 AWG stranded (7×36) tinned copper
2. INSULATION: Polypropylene
3. JACKET: Chrome PVC, see Chart 3 for color code
4. SHIELDING: Overall Beldfoil (100% coverage) and tinned copper braid shield (90% coverage),
28 AWG stranded tinned copper drain wire
5. STANDARDS: UL AWM Style 2960, NEC: CL2
6. RATINGS: 30 V (AWM), 150 V (CL2), -20°C to 60°C, 100 ohm nominal impedance, 66% velocity of propagation, 15.5 pF/ft. capacitance

B9804, B9805, B9806, B9807, B9808, B9809, B9812, B9813, B9819, B9825, B9814
